29
Figure 25 Line Section Assembly (S/N 1723 & below)
Item No. Description Part No. Qty
Figure 25
1 Line Section, Subassembly 4381-005 1
2 PC Board, Data Acquisition Assy 4391A006 1
3 Bead, Keying 4391-026 2
4 Spacer 4391-027 2
5 Screw, Machine, filister head,
No. 4-40, 1/4 in. lg, sst
COML 2
6 Support 4381-029 2
7 Screw, Machine, filister head,
No. 8-32, 1/2 in. lg, sst
COML 4
8 Screw, Machine, filister head,
No. 4-40, 7/8 in. lg, sst
COML 2
9 Spacer 4391-035-1 2
10 Cover, PC Board 4391-034 1
11 Lock Washer, No. 4 internal sst COML 2
N/A Line Section Complete 4391-014 1
