Maintenance
31
Replacement Parts List
Models 8655B and 8656B
* Load resistors installed per models listed in specifications.
Item Qty. Description Part Number
1 1 RF Load Resistor (Econoload):
Model 8655
Model 8656
8775-100*
8776-100*
2 1 Switch, Rocker 5A2384
3 1 AC Connector (Fuse Casing) 5-1844
4 1 Line Cord:
115V
230V
5-1836
5-1837
7 1 Relay, Time Delay 5A2787-1
10 1 Thermoswitch (79°C) 5A2788-1
12 1 Coolant tank Assy. 8650B030
13 1 Terminal strip assembly 8640-682
14 1 Pump/Motor/Bracket Assembly:
230V 60Hz
115V 50Hz
230V 50Hz
115V 60Hz
RPK8650-60-230
RPK8650-50-115
RPK8650-50-230
RPK8650-60-115
15 1 Drain Plug 8640-036
16 4 Handle - 90°, 2 position 5-882
17 1 Coolant gauge (replacement kit) 5-1200
18 1 Ethylene Glycol coolant 5-1134-3
19 1 Fuse Drawer
115 VAC
230 VAC
5-1845-FD
5A2310
20
1
2
Fuse
115 VAC (3AB Time Delay 15 amp 250V)
230 VAC (5x20, Time Delay, 8 amp, 250V)
5-1828-36
5A2257-25
Fan
864-5-115 (115 VAC)
864-5-230 (230 VAC)
5A2770-1
5A2770-2
Fan panel assembly (includes fans, panel, wiring)
115 VAC
230 VAC
8650B003-1
8650B003-2
