Page 17

Chapter 3

Operating Instructions

This chapter provides information for on-site requirements,

unpacking, inspection, and preparing the equipment for use.

Site and

Shelter

Requirements

The Model 8329-300 Attenuator should be operated in a dry,

dust, and vibration free environment. The ambient tempera-

ture range should remain between -40°C and +45°C (-40°F

and +113°F) for proper operation. Allow at least 12"

(300mm) of clearance around the unit, 6" (150mm) if it is

equipped with a blower, to permit unimpeded access of con-

vection air currents for adequate heat dissipation. To permit

the shortest possible cable length, place the attenuator as

close as possible to the transmitting equipment.

Unpacking

and

Inspection

Follow the steps below when unpacking the equipment.

1. Inspect the shipping container for

signs of damage. If damage is noticed,

do not unpack the equipment. Immedi-

ately notify the shipping carrier and

Bird Electronic Corporation of the

damage.

2. If the shipping container is not dam-

aged, unpack the unit. Save all ship-

ping materials for repackaging.

3. Inspect all components for visual signs

of damage. Immediately notify the

shipping carrier and Bird Electronic

Corporation of equipment damage or

missing parts.

Tools

Required

The following tools and supplies will be required to prepare

the unit for use.

Wrenches

Standard screwdrivers

9/16 Hex wrench (for thermoswitch installa-

tion)

Pipe sealing compound (for thermoswitch in-

stallation)

Soldering Iron and solder (for thermoswitch in-

stallation)
