Chapter 5
Maintenance
This chapter contains operator maintenance instructions, troubleshooting, and parts
information.
Troubleshooting
Cleaning
The most important cleaning task is to remove accumulations of dust and lint from
the radiator fins. An extensive collection of dust and lint on the cooling fins will
interfere with the efficient dissipation of heat.
When dirt and dust have accumulated in the radiator fin spaces it should be cleaned.
Preparation:
s Material: Lint-free cleaning cloth
s Mild detergent
To clean the unit follow the instructions below.
1. Gently remove loose dirt and grime using a soft clean cloth dampened with a mild
warm solution of detergent and water.
2. Check the condition of the RF coaxial connector. If it needs cleaning, clean the
connector with a self-drying contact cleaner, that leaves no residue on the inaccessible
portions.
Preventive Maintenance
Measure dc
Resistance
Preparation:
s Tools: Common hand tools
Problem Possible Cause Remedy
Leaking of coolant oil around clamping
band or radiator housing. Clamping band not tight. Tighten slightly with a
screwdriver.
Faulty O-Ring (Input) Replace, refer to the
Coolant paragraph
Faulty O-Ring (Output) Replace, refer to the
Coolant paragraph
Excessive overheating of the radiator. Transmitter power too high Reduce transmitter power
Faulty RF section assembly Replace, refer to Coolant
paragraph
Coolant oil level too low Add more coolant oil to
the radiator.
High or low dc resistance values per the
Measure dc Resistance paragraph. Faulty RF input connector Replace the input
connector per the RF
Connector paragraph.
Loose RF input connector Tighten the input
connector with a
screwdriver.
Faulty RF section assembly. Replace per the Coolant
paragraph.
11
