Chapter 3
Installation
This chapter provides information for on site requirements, unpacking, inspection,
and preparing the equipment for use.
Site and Shelter
Requirements
The Model 8327-300 Attenuator should be operated in a dry, dust and vibration free
environment. The ambient temperature range should remain between -40°C and
+45°C (-40°F and +113°F) for proper operation. Allow at least 12" (305 mm) of
clearance around the unit to permit an unimpeded access of convection air currents
for adequate heat dissipation. To permit the shortest possible cable length, place the
attenuator as close as possible to the transmitting equipment.
Unpacking and
Inspection
Follow the steps below when unpacking the equipment.
1. Inspect the shipping container for signs of damage. If damage is
noticed, do not unpack the equipment. Immediately notify the ship-
ping carrier and Bird Electronic Corporation of the damage.
2. If the shipping container is not damaged, unpack the unit. Save all
shipping materials for repackaging.
3. Inspect all components for visual signs of damage. Immediately notify
the shipping carrier and Bird Electronic Corporation of equipment
damage or missing parts.
Tools Required The following tools and supplies will be required to prepare the unit for use.
s Wrenches
s Screwdrivers
s 9/16 Hex wrench (for thermoswitch installation)
s Pipe sealing compound (for thermoswitch installation)
s Soldering Iron and solder (for thermoswitch installation)
s Bolt and nut sets or lag screws (for mounting)
Mounting
CAUTION
This equipment is designed for operation in a horizontal position only, with mounting
brackets down. Do not operate in any other manner.
The attenuator may stand free or may be secured to a bench or any convenient flat
surface. The front and rear face plates are made of heavier gauge material bent
outward 90° at the bottom to form mounting flanges. At each corner if these flanges
is a 3/8 inch x 15/32 inch elongated hole for use with suitable fasteners up to 3/8
inch. The holes are arranged in a 20-23/32 inch x 4-1/2 inch rectangle (526.3 x 114.3
mm). The front and rear face plates of the attenuator are also bent over on the top
to form convenient carrying handles. The following instructions are for mounting the
unit to a suitable surface.
1. Place the unit on a flat surface.
2. Insert the fasteners, up to 3/8 inch, through the bench and the holes.
3. Secure the bolts with nuts and lock washers.
