Bird Multi-Sensor Cal Cart System

18

Bird 4027F Series RF Power Sensors

Frequency Range

4027F2M
4027F10M

1.8 – 2.2 MHz
12 – 15 MHz

RF Power Range

4027F2M, 4027F10M

0.1 – 10 kW

Accuracy, Fwd, Best Case

± 1.0% (2

σ

)

Calibration Frequencies,

Typical

*

4027F2M
4027F10M

* Other calibration frequencies available upon request

1.8, 2.0, 2.17 MHz
12.0, 12.5, 13.56, 14.0, 15.0 MHz

Calibration Power, Typical

1.7 kW

Harmonic Rejection, Min.

4027F2M
4027F10M

26 dB @ 3.6 – 3.8 MHz, 30 dB @ > 3.8 MHz
30 dB @ > 25 MHz

Low Frequency Rejection, Min.

4027F10M

30 dB @ < 1 MHz

Max Error Induced by 10% AM

4027F2M, 4027F10M

0.2% @ < 5 kW, 1.0% @ 5 – 10 kW

VSWR, Max.

1.05:1

Insertion Loss, Max.

0.05 dB (with female “N” connectors)

Directivity, Min.

28 dB

Uncertainty Budget, 4027F Series

*

* All values 2

σ

4027F2M

4027F10M

Frequency
Error...

at cal freq

± 0.1%

± 0.1%

not at cal freq

± 0.5%

± 1.5%

Power
Linearity...

at cal power

± 0.1%

± 0.1%

not at cal power

± 1.0%

± 0.5%

Temperature
Uncert...

within 20 to 30°C

± 0.65%

± 0.6%

outside 20 to 30°C

± 3.2%

–3.0, +0.75%

Calibration Uncertainty

± 0.6%

± 0.6%

Resolution
Uncert...

at cal power

± 0.06%

± 0.06%

not at cal power

† Resolution uncertainty is error due to limited display digits. Actual

uncertainty can be calculated as

± (1 in least significant digit) / Reading

For a 3.5-digit display, worst case is at 300W. Least significant digit is

one watt, uncertainty is ± 1W out of 300 or 0.34%. For a 4.5-digit

display, least significant digit is 0.1W, so the uncertainty is 0.034%

± 0.34%

± 0.34%

Other sources of error

± 0.4%

± 0.5%

Best Case RSS Uncertainty

± 1.0%

± 1.0%
