Bird Multi-Sensor Cal Cart System

4

1. Remove the shipping plugs from the load.
2. Install the vent plugs, shown in Figure 2.

Note:

The AC power supply required is 115/230 V @ 50/60 Hz, 1f.

The unit is equipped with an IEC 320 “cold” (65°C) AC inlet.

Note:

If the load is not equipped with a blower, then the Bird Cal Cart

may run on battery power after the 4421’s batteries have been charged.

3. Slide the safety cover to expose the desired sensor connector.

Note:

To connect the Cal Cart to the RF source, use 50 ohm coaxial

cable suitable for the frequency and power level of operation. Use a con-
nector which will mate with the cart’s exposed RF connector.

CAUTION

Use the Bird Cal Cart in a dry, dust and vibration free environment. Do not

use outdoors or in areas of condensing humidity. Allow at least 12" (30 cm)

of clearance around the load.

WARNING

RF Safety Cover provides protection against RF power.

Do not defeat this safety device.
