right to scroll through the setting choices. When a desired choice is found,
simply leave it at that choice to select it.
Changing Operating Modes
Changing the selection in Param 0 from “UP” to “HF” selects the operating
mode of the board and results in alternate sets of parameters and
definitions. The two tables that follow show the parameter choices and
definitions available when the board is in Upconvert or HD Framesync
mode. Making a change in Param 0 results in an alternate bitfile to be
loaded and the HD Framesync H and V output timing params to be loaded
into the registers. During the bitfile loading process you may notice a short
delay when the switches are not responsive. After the process completes,
the unit will return to the status display.
In the Status display, which is active when the unit's switches have not
been toggled for 5 seconds or more, an “H” will appear in the character 1
position if the unit is in HD Framesync mode—and there is a valid HD signal
present on both the video input and the genlock input (the two must
match).
Parameter Choices and Definitions When in Upconvert
Mode
Table 4.
Parameter
(Character 1)
Definitions
(Choices are shown in italics)
0 Selects a Mode of operation for the board. Choices are:
UP—up convert
HF—high definition framesync
1 Output Format. Choices are:
li—1080i 59.94Hz
7p—720p 59.94Hz
A—automatic; output follows the tri-sync input (default)
2 Upconvert Mode. Choices are:
43—4x3 pillar box format
14—14x9 pillar box format (default)
FS—full-screen (anamorphic display) format
LB—16x9 letterbox input to full
WZ—wide zoom format
5 Output Timing Mode, Set Reference Source. Choices are:
R—reference input
I—video input
F—free run (default)
6 ON—allows VITC timecode and Closed Caption (CC) information
to be passed on lines 20 and 21.
OFF—lines 20 and 21 are blanked (default).
