6
Editing and
Viewing Board
Settings Adjust
Mode Moving the PS switch in either direction causes the RH10UC to enter adjust
mode . When this happens, the display will change to indicate the
parameter being shown/edited.
When a parameter is shown in adjust mode, the last selected parameter is
shown in character 1and the current parameter value is shown in
characters 2 through 4—if the value exceeds 3 digits, then all 4 characters
in the display are used to show the value. Parameter choices and their
definitions are listed in a table on the following page.
Selecting Parameters
Move the PS switch to the left to increment the parameter number or move
it to the right to decrement the parameter number. Characters 2 through 4
will change to reflect the settings of these parameters as they are
incremented/decremented.
Editing Parameters
When a parameter has been selected with the PS switch, use the PA switch
to then change the parameter value (as displayed by characters 2 through
4) to another value. Like the PS switch, you’ll move PA switch to the left or
Table 2.
Character # Indicates
1 S—Standard Definition (SD) input signal present
E—Error on input signal
H—High definition signal present (HD Framesync mode only)
2 Blank—not used
3 or 4 Mode Mnemonic: these codes show what the board is doing
UP—up convert
HF—High Definition Framesync
Table 3.
Character # Indicates
1 Normally displays parameter number 0 through 9, and A to Z
(some numbers and letters are currently not used—only those
used will be discussed in this document).
If the parameter value (see below) exceeds 3-digits, this display
character will also be used so 4-digits of the value can be viewed.
1 to 4 A 1 to 4-character code that indicates a parameter value.
Usually the value will be shown in characters 2 through 4, except
when the value requires all 4 characters.
