AJA RH10UC SD to HD Upconverter User Manual
Specifications
Item
Specification
Input Formats
525/59.94, 625/50, SMPTE 259M
Output Formats
1080i 50/59.94, 720p 59.94 Hz (50Hz output requires 50 Hz input)
Upconversion
Motion adaptive, Multi-point interpolation, 10-bit processing
Inputs SDI,
BNC
Reference
2 x BNC, looping
Outputs
Input Loop, 2 x BNC, Equalized
HD-SDI, 4 x BNC
User Controls
Mode: Upconvert, Frame Synchronizer, Output Format, Aspect
Ratio Convert Select, and Output Timing
Size:
Fits AJA R-Series Frames
Compatible With Leitch® 6800 Series Frames
Power Consumption:
6 watts
