3 AJA RH10UC SD to HD Upconverter User Manual
Features
• Full 10-bit broadcast quality SD to HD upconverter mode of operation
• HD Framesync mode of operation
• 8/10 bit SMPTE 259 SDI input, 2 re-clocked outputs
• 8/10 bit SMPTE 292 HD-SDI output, 4 outputs
• 8 Channels of Embedded SDI Audio are supported in Upconvert mode
(audio is not supported in HD Framesync mode)
• bi/tri-level sync genlock input, 2 BNC loop-through with adjustable
output timing
• 4:3 or 16:9 SD inputs
• 4:3 to 16:9 conversion modes:
4:3 pillar box (4:3 image in center of screen, black sidebars)
14:9 pillar box (4:3 image zoomed to fill a 14:9 image, black sidebars)
Full Screen (for anamorphic inputs)
Letterbox (input 16:9 letterbox is zoomed to full screen)
Widezoom (a combination of zoom and horizontal stretch to fill 16:9
screen; will introduce a small aspect ratio error)
• Separate multipoint H and V filters
• Motion adaptive interpolation
• 16 bit coefficients, 16 bit internal data paths
• Accurate 16 bit SD to HD colorspace conversion
• 1 slot AJA FR1 or FR2 frame
Upconverter Specifications
Table 1.
Item Specification
Input SDI (525 or 625) in Upconvert Mode
HD SDI (1080i or 720p ) in HD Framesync Mode
Output HD SDI (1080i or 720p)
Delay 1 Frame. Audio is delayed to compensate for the delay
through the video path.
Power 7 Watts
