Trusted
TM
I/O Companion Slot Cables TC-200
Issue 14 Apr 10 PD-TC200 7
The types of Trusted TM I/O Companion Slot Cables currently available are listed in Table 1 below
Cable Type Description
TC-201-01-xmx I/O Companion Slot, Internal, 40 Channel Input to FTA
TC-201-02-xmx I/O Companion Slot, Internal, 40 Channel Input to FTA
TC-202-01-xmx I/O Companion Slot, Internal, 40 Channel Input to Flying lead / Free wire
TC-202-02-xmx I/O Companion Slot, Internal, 40 Channel Input to Flying lead / Free wire
TC-203-01-xmx I/O Companion Slot, External, 40 Channel Input to FTA
TC-203-02-xmx I/O Companion Slot, External, 40 Channel Input to FTA
TC-204-01-xmx I/O Companion Slot, External, 40 Channel Input to Flying lead / Free wire
TC-204-02-xmx I/O Companion Slot, External, 40 Channel Input to Flying lead / Free wire
TC-205-01-xmx I/O Companion Slot, Internal, 40 Channel Output to FTA
TC-205-02-xmx I/O Companion Slot, Internal, 40 Channel Output to FTA
TC-206-01-xmx I/O Companion Slot, Internal, 40 Channel Output to Flying lead / Free wire
TC-206-02-xmx I/O Companion Slot, Internal, 40 Channel Output to Flying lead / Free wire
TC-207-01-xmx I/O Companion Slot, External, 40 Channel Output to FTA
TC-207-02-xmx I/O Companion Slot, External, 40 Channel Output to FTA
TC-208-01-xmx I/O Companion Slot, External, 40 Channel Output to Flying lead / Free wire
TC-208-02-xmx I/O Companion Slot, External, 40 Channel Output to Flying lead / Free wire
TC-209-01-xmx I/O Companion Slot, Internal, 40 Channel Output to VFTA
TC-209-02-xmx I/O Companion Slot, Internal, 40 Channel Output to VFTA
TC-210-01-xmx I/O Companion Slot, External, 40 Channel Output to VFTA
TC-210-02-xmx I/O Companion Slot, External, 40 Channel Output to VFTA
TC-211-01-xmx I/O Companion Slot, Internal, 40 Channel Input to VFTA
TC-211-02-xmx I/O Companion Slot, Internal, 40 Channel Input to VFTA
TC-212-01-xmx I/O Companion Slot, External, 40 Channel Input to VFTA
TC-212-02-xmx I/O Companion Slot, External, 40 Channel Input to VFTA
TC-215-01-xmx I/O Companion Slot Internal 40 Channel Output to FTA ( Integral Power )
TC-215-02-xmx I/O Companion Slot Internal 40 Channel Output to FTA ( Integral Power )
TC-216-01-xmx I/O Companion Slot Internal 40 Channel Output to Flying lead / Free wire ( Integral Power )
TC-216-02-xmx I/O Companion Slot Internal 40 Channel Output to Flying lead / Free wire ( Integral Power )
TC-217-01-xmx I/O Companion Slot External 40 Channel Output to FTA ( Integral Power )
TC-217-02-xmx I/O Companion Slot External 40 Channel Output to FTA ( Integral Power )
TC-218-01-xmx I/O Companion Slot External 40 Channel Output to Flying lead / Free wire ( Integral Power )
TC-218-02-xmx I/O Companion Slot External 40 Channel Output to Flying lead / Free wire ( Integral Power )
TC-219-01-xmx I/O Companion Slot Internal 40 Channel Output to FTA with Power Distribution Flying Lead
Extension
TC-219-02-xmx I/O Companion Slot Internal 40 Channel Output to FTA with Power Distribution Flying Lead
Extension
TC-221-01-xmx I/O Companion Slot Internal 16 Channel AC Output to T8871 FTA ( Integral Power )
TC-221-02-xmx I/O Companion Slot Internal 16 Channel AC Output to T8871 FTA ( Integral Power )
TC-222-02-xmx I/O Companion Slot Internal 16 Channel Isolated AC Output to T8873 FTA ( Integral Power )
Table 1 Trusted TM I/O Companion Slot Cables
