Ontents – Rockwell Automation SA500 DC Bus Supply User Manual
Page 3

Table of Contents
I
C
ONTENTS
Chapter 1
Introduction
1.1
Related Publications ........................................................................................ 1-2
1.2
Related Hardware............................................................................................ 1-2
Chapter 2
Mechanical/Electrical Description
2.1
Mechanical Description ................................................................................... 2-1
2.1.1 LED Indicators....................................................................................... 2-2
2.1.2 Interface Connector (TB1)..................................................................... 2-2
2.2
Electrical Description ....................................................................................... 2-3
Chapter 3
Installation Guidelines
3.1
Selecting a DC Bus Supply ............................................................................. 3-2
3.2
Selecting an External Braking Resistor ........................................................... 3-3
3.3
Wiring .............................................................................................................. 3-4
3.4
Grounding ........................................................................................................ 3-4
3.5
DC Bus Supply Initial Installation..................................................................... 3-5
3.6
Replacing the DC Bus Supply ....................................................................... 3-10
Chapter 4
Diagnostics and Troubleshooting
4.1
DC Bus Supply Faults ..................................................................................... 4-1
4.1.1 The PHASE LOSS LED Is On............................................................... 4-1
4.1.2 The OVERTEMP LED Is On ................................................................. 4-1
4.1.3 The PSM READY LED Is Off ................................................................ 4-2
4.2
DC Bus Braking Fuse Is Blown ....................................................................... 4-2
Appendix A
Technical Specifications ...........................................................................................A-1
Appendix B
Block Diagram ..........................................................................................................B-1
Appendix C
Motor Current Specifications ....................................................................................C-1
Appendix D
Compliance with Electromagnetic Compatibility Standards......................................D-1
Index
........................................................................................................................... Index-1
