Rockwell Automation TC300 Trusted Communications Cables - Manual (Page 12)

Trusted
TM
Communication Cables TC300
Issue 13 Oct 11 PD-TC300 12
Connection Type SK1 Pin Function Core Colour
S1 50 OHM CO-AX INNER CORE E1
Ethernet 1
10 Base 2
S1 GND OUTER SCREEN
21a TD+1 WH/OG
21b TD-1 OG
22a RD+1 WH/GN
22b RD-1 GN
E2
Ethernet 2
10 Base T
SCREEN
S2 50 OHM CO-AX INNER CORE E3
Ethernet 3
10 Base 2
S2 GND OUTER SCREEN
25a TD+2 WH/OG
25b TD-2 OG
26a RD+2 WH/BU
26b RD-2 BU
E4
Ethernet 4
10 Base T
SCREEN
5a TXD1 RS232 WH/OG
6a RTS1 RS232 WH/BN
6b DTR1 RS232 WH/BU
6c RXD1 RS232 OG
7a CTS1 RS232 BN
7b DSR1 RS232 BU
8a RXB1 RS422/485 BN
8b RXA1 RS422/485 WH/BN
9a TXB1 RS422 WH/BU
9b TXAO RS422 BU
9c GND 0 RS232 SCREEN
S1
Serial Port 1
RS232
RS422/485
4c to 29a LINK RS232
11a TXD2 RS232 WH/OG
11c RXD2 RS232 OG
12a RXB2 RS422/485 BN
12b RXA2 RS422/485 WH/BN
13a TXB2 RS422 WH/BU
13b TXA2 RS422 BU
S2
Serial Port 2
RS232
RS422/485
13c GND 2 SCREEN
15a RXB3 RS422/485 WH/OG
15b RXA3 RS422/485 OG
16a TXB3 RS422 WH/BU
16b TXA3 RS422 BU
S3
Serial Port 3
RS422/485
16c GND 3 SCREEN
18a RXB4 RS422/485 WH/OG
18b RXA4 RS422/485 OG
19a TXB4 RS422 WH/BU
19b TXA4 RS422 BU
S4
Serial Port 4
RS232
RS422/485
19c GND4 SCREEN
Table 2 TC-305-01 Pin Connections
