3.2.7. Rack 7: HKEEPING
Channel
Description
FCR Units (Full Scale Range)
1 A
24V2 Input Voltage -32768 32767 mV 2 B
3 C
4 A
Internal supply voltage (post regulator) -32768 32767 mV 5 B
6 C
7 A
Internal supply current (post regulator) -32768 32767 mA 8 B
9 C
10 A
Input voltage (post isolation) -32768 32767 mV 11 B
12 C
13 A
24V1 Input Voltage -32768 32767 mV 14 B
15 C
16 A
HIU Board Temperature
(Note: Temperature, ºC = input value / 256)
-32768 32767 - 17 B
18 C
19 A
Front Panel Load Current -32768 32767 mA 20 B
21 C
22 A
SmartSlot Link Voltage -32768 32767 mV 23 B
24 C
25 A
Reserved for FIU condensation sensor 0 0 - 26 B
27 C
28 A
FIU Internal Supply Voltage -32768 32767 mV 29 B
30 C
31 A
FIU Internal Supply Current -32768 32767 mA 32 B
33 C
34 A
FIU Unregulated input voltage -32768 32767 mV 35 B
36 C
37 A
FIU Board Temperature
(Note: Temperature, ºC = input value / 256)
-32768 32767 - 38 B
39 C
40 A
FIU Reference Voltage, DAC_X1 -32768 32767 mV 41 B
42 C
43 A
FIU Reference Voltage, DAC_X2 -32768 32767 mV 44 B
45 C
46 A
FIU Reference Voltage, DAC_X3 -32768 32767 mV 47 B
48 C
49 A
Diagnostic error code
50 B
51 C
Table 12 Rack 7: Housekeeping
