1. Product Range
Catalogue No.
Product name
Description
T8230
Power Shelf
19” x 1U chassis for up to 3 Power Packs. Includes
4U fixing kit, Power Port (with push fit BLZF 3.5/10
connector), mains plugs and retaining clips.
T8231
Power Pack 24Vdc
750Watt, universal input, 24Vdc out.
T8232
Power Pack 28Vdc
750Watt, universal input, 28Vdc out.
T8233
Power Port
Plug in diagnostic interface.
T8234
Power Controller
For live adjustment of output voltage. 19” x 1U.
T8235
Power Shield
Covers unused Power Pack positions
TC-323
Power Shelf
Interconnect
For connection to a Power Controller or for current
sharing
Table 1 T823X Power System Product Range
