PowerFlex® 700S and 700H Frame 12 DC Bus Connector Kit
4. Secure a M10 insulated standoff (larger size) to the bracket on the air flow
plate using a M10x12 bolt and flat and lock washer as shown below.
Important: The standoff must be secured to the hole furthest from the air
flow plate.
Insulated standoff
