Trusted TM
AN-T80020 Diagnostics Procedure
Issue 12 Feb 11 AN-T80020 69
FIA_NOT_PRESENT
0x8801
Modules:All
Appears on startup. Detects a missing or misaligned field interface
assembly or ribbon cable. It also detects faults in the field interface
power system that result in little or no current flow from the host
interface, or a faulty current monitor. The slice will not boot.
Re-insert the module; if it fails again, return the module for repair.
FIA_POWERUP_ERROR
0x8802
Modules:All Appears on startup. The field interface drew too much current on more
than one quadrant on startup and was prevented from dragging down
the host interface. The slice will not boot.
Re-insert the module; if it fails again, return the module for repair.
FIA_CONFIGURE_TIMEOUT
0x8803
Modules:All Appears on startup. The field interface took too long to be configured.
The slice will not boot.
Re-insert the module; if it fails again, return the module for repair.
FIA_ISL_TIMEOUT1
0x8804
Modules:8442, 8472 Before configuring the field interface, all slices must be synchronized.
This took too long. The slice will not boot.
Return the module for repair.
FIA_OVERCURRENT
0x8806
Modules: 8442, 8472 The field interface drew too much current on one quadrant.
The slice will not boot.
Return the module for repair.
0x9000 Series Codes (Host Interface Unit non-resettable)
HIU_DSP_CORE_FAULT
0x90nn
Modules:All
Subcode:nn = returned DSP test
result register Checks the operation of the DSP Core using its self-test functions.
Detects internal DSP faults.
Return the module for repair.
Action:Slice OFFLINE
HIU_MEMORY_ACCESS_FLT
0x9001
Modules:All Detects faulty memory in the interface to the IMB.
Return the module for repair.
Action:Slice OFFLINE
HIU_FCRID_FAULT
0x9002
Modules:All Detects a fault in the hard-wired slice ID code.
Return the module for repair.
Action:Slice OFFLINE
0xC000 Series Codes (Module firmware non-resettable)
APP_STACK_FAULT
0xC003
Modules:All Checks for application firmware errors that corrupt the stack.
Report to ICS Triplex Technology.
Action:Slice OFFLINE
APP_TASK_TIMEOUT
0xC005
Modules:All except 8480 Application firmware failed to reset the hardware watchdog (e.g. it is
locked in a loop). The hardware watchdog will turn off the slice.
Report to ICS Triplex Technology.
Action:Slice halted
