2 Inverting Fault Circuit Breaker Kit for FlexPak 3000 and WebPak 3000 Drives
Installing the Inverting Fault Circuit Breaker
Installing the Inverting Fault Circuit Breaker Kit involves the following processes:
• Mounting the Inverting Fault Circuit Breaker Kit
• Wiring the Inverting Fault Circuit Breaker
• Removing and Replacing Fuse 11FU
• Connecting the Wire Assembly
• Checking the Circuit Breaker Settings
Table 2 – Contents of the Inverting Fault Circuit Breaker Option
Description Quantity Part Number
Inverting Fault Circuit Breaker Assembly 1 802273-85x
M5 x 10 Self-Tapping Screw 4 419062-100PHG
Jumper
1
610273-30RN
Bus Bar
1
610273-101A
Bus Bar
1
610273-102A
Ring Lug 1 68321-19D
Wire Harness
1
610273-68S
Wire Harness
1
610273-68R
!
ATTENTION: The drive is at line voltage when disconnected to incoming AC power. Disconnect,
tag, and lock out all incoming power to the drive before performing the following procedures.
Failure to observe this precaution could result in severe bodily injury or loss of life.
ATTENTION: The user is responsible for conforming with all applicable local, national, and
international codes. Failure to observe this precaution could result in damage to, or destruction
of, the equipment.
