Standard Power Cables with SpeedTec DIN Connector Type 923 7
Publication 2090-IN022A-EN-P - September 2010
Specifications
Additional specifications for each cable are available in the Kinetix Motion Control Selection
Guide
, publicat
2090-CPBM7DF-xxAAxx Specifications
2090-CPWM7DF-xxAAxx Specifications
Attribute Value
Wire Size
16 AWG
14 AWG
12 AWG
Diameter
11.6 mm (0.47 in.)
12.7 mm (0.50 in.)
14.3 mm (0.56 in.)
Bend Radius
115 mm (4.5 in.)
130 mm (5.0 in.)
145 mm (6.0 in.)
Installation Areas
(1)
(1)
The installation areas are approximately 300 mm (12 in.) in length at both ends of the cable. Secure this area with a rigid
mount that prevents the cable from flexing where it connects to other components.
Attribute Value
Wire Size
16 AWG
14 AWG
12 AWG
Diameter
9.2 mm (0.36 in.)
10.3 mm (0.40 in.)
11.3 mm (0.44 in.)
Bend Radius
100 mm (4.0 in.)
105 mm (4.0 in.)
115 mm (4.5 in.)
Installation Areas
(1)
(1)
The installation areas are approximately 300 mm (12 in.) in length at both ends of the cable. Secure this area with a rigid
mount that prevents the cable from flexing where it connects to other components.
