Introduction, Download powerflex 7000 software updater – Rockwell Automation 7000 HMI Interface Board Software Updater and Firmware Download Procedure User Manual
Page 3
Rockwell Automation Publication 7000-QS002A-EN-P - October 2012
3
HMI Interface Board Software Updater and Firmware Download Procedure
Introduction
The procedure is only applicable to PowerFlex® 7000 ForGe Drives which utilize the new HMI Interface Board
(Part No. 80190-780-01-R).
The HMI Interface Board Software Updater and Firmware Download Procedure
is necessary when:
•
Retrofitting existing PowerFlex 7000 ForGe Drive with the new HMI Interface Board, and/or
•
Updating PowerFlex 7000 ForGe Drive Firmware and HMI Interface Board Firmware simultaneously with the most
recent firmware versions.
Download PowerFlex 7000 Software Updater
1.
Enter the following website to access the Allen-Bradley updates page.
IMPORTANT
System firmware refers to PowerFlex 7000 ForGe Drive Firmware, the HMI Interface Board Firmware and the SD card generic
content.
When replacing an existing HMI Interface Board, the existing SD card must be placed into the new HMI Interface Board. An
existing SD card contains all the job specific documentation (e.g. user manuals, customer drawings, etc.).
The updater utility does not update this documentation.
