12 Input/12 Output Discrete Embedded TTL I/O Module with Pulse Width Modulation and DeviceLogix
Publication 1799-IN008A-EN-P - July 2005
The module is equipped with AutoBaud detect, and is shipped with Autobaud
enabled. AutoBaud lets the module detect the baud rate on your DeviceNet
network and automatically adjusts the module to that rate.
Your package contains:
• one I/O module
• these installation instructions
• one DeviceNet 5-position, open-style plug with 2 locking screws (catalog
number 1799-DNETSCON)
Optional Hardware
Order all mating connectors and mounting hardware separately.
Option
Quantity
Catalog Number
Supplier
12-position I/O connector (2 pieces)
1
1799-12SPCON
Rockwell Automation
Hex stand-off, M3, 1 cm (1/4 in.)
Minimum length 1 cm (1/4 in.)
6
N/A
Local purchase
Screw, Pan Head, #6
6
N/A
Local purchase
31568-M
