Refer to the following table for the word/bit definitions for the 1799-12G12GL
boards
Configure Module Parameters
The module has 11 parameters that are configurable through a DeviceNet software
configuration tool such as RSNetWorx for DeviceNet. The DeviceNet configuration
tool requires an electronic data sheet (EDS) to configure the module’s parameters.
You can find the EDS file on the ODVA Web site (www.odva.org).
Use the descriptions in the following table to help you configure the parameters.
Byte
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
Bit 0
Produced 0
I7
I6
I5
I4
I3
I2
I1
I0
Produced 1
Reserved
Logic Enabled Reserved
Reserved
I11
I10
I9
I8
Produced 2
O7
PWM Enabled 1
O6
05
04
O3
PWM Enabled 0
O2
O1
O0
Produced 3
O15
PWM Enabled 3
O14
O13
O12
O11
PWM Enabled 2
O10
09
O8
Produced 4
NetOut 7
NetOut 6
NetOut 5
NetOut 4
NetOut 3
NetOut 2
NetOut 1
NetOut 0
Produced 5
NetOut 15
NetOut 14
NetOut 13
NetOut 12 NetOut 11
NetOut 10
NetOut 9
NetOut 8
Consumed 0 O7
O6
O5
O4
O3
O2
O1
O0
Consumed 1 O15
O14
O13
O12
O11
O10
O9
O8
Consumed 2 PWM 7
PWM 6
PWM 5
PWM 5
PWM 4
PWM 3
PWM 2
PWM 1
Where: I = Input; O = Output; PWM = Pulse Width Modulation
PWM 0 through 7 = Pulse Width Modulation percent value
Parameter
Description
AutoBaud
Enables the board to match the network’s data rate. When
enabled, Baud Rate parameter is ignored.
Input Off-to-On Filter Time
Controls the amount of time the input must be in the on
state before the board reports the input as on.
Input On-to-Off Filter Time
Controls the amount of time the input must be in the off
state before the board reports the input as off.
Output Idle State
Controls the state of each output when the DeviceNet
master is in an idle state.
Output Fault State
Controls the state of each output when the board loses
communication with the DeviceNet master.
Output Idle Value
Controls the value that outputs will have when the output
idle state is set to use idle value.
