Industrial 10.4" Flat Panel Monitor

Publication 6185-5.0

Step 4 - Adjust the vertical position

Press and hold the V button on the back panel of the monitor until
the Fault Active Indicator begins to blink (red).

Use the + and - buttons to adjust the vertical screen position.

To exit this mode and save the new position, quickly press the V
button. To exit without saving, press the Rst button.

Step 5 - Adjust the clock phase

Use the Clk control to adjust the clock phase of the monitor to match the
video clock rate. Adjust the control until the screen image is sharp and
there is no screen “jitter.” The change should be most apparent in the
vertical lines of the screen image.

Step 6 - Adjust the brightness and contrast

Use the Contrast ( ) control to adjust the difference between the
light and dark elements in the screen image.

Use the Brightness (

) control to adjust the overall intensity of the

screen image.

Note:

Allow time for the backlight on the monitor to warm up
completely before you adjust the brightness control.
