14 Micro830 10 Point Programmable Controllers
Publication 2080-IN002B-EN-P - April 2014
Insulation stripping
length
7 mm (0.28 in.)
Enclosure type rating
Meets IP20
North American temp
code
T4
(1)
Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation
Wiring and Grounding Guidelines, publication
Input Specifications
Attribute
High-speed DC input
(Inputs 0…3)
Standard DC input
(inputs 4 and higher)
Number of inputs
4
2
Input group to
backplane isolation
Verified by one of the following dielectric tests: 1,414V DC for 2 s
75V DC working voltage (IEC Class 2 reinforced insulation)
Voltage category
24V DC sink/source
Off-state voltage, max
5V DC
On-state voltage range
16.8…26.4V DC @ 65°C (149°F)
16.8…30.0V DC @ 30°C (86°F)
10…26.4V DC @ 65°C (149°F)
10…30.0V DC @ 30°C (86°F)
Off-state current, max
1.5 mA
On-state current, min
5.0 mA @ 16.8V DC
1.8 mA @ 10V DC
On-state current, nom
7.6 mA @ 24V DC
6.15 mA @ 24V DC
On-state current, max
12.0 mA @ 30V DC
Nominal impedance
3 k
Ω
3.74 k
Ω
IEC input compatibility
Type 3
AC input filter setting
8 ms for all embedded inputs
In Connected Components Workbench, go to the Embedded I/O
configuration window to reconfigure the filter setting for each
input group.
Output Specifications
Attribute
2080-LC30-10QWB
2080-LC30-10QVB
Relay Output
High-Speed Output
(Outputs 0…1)
Standard Output
(Outputs 2…3)
Number of outputs
4
2
2
General Specifications
Attribute
2080-LC30-10QWB
2080-LC30-10QVB
