Micro830 10 Point Programmable Controllers 13
Publication 2080-IN002B-EN-P - April 2014
Specifications
General Specifications
Attribute
2080-LC30-10QWB
2080-LC30-10QVB
Number of I/O
10 (6 inputs, 4 outputs)
Dimensions,
HxWxD
90 x 100 x 80 mm
(3.54 x 3.94 x 3.15 in.)
Shipping weight,
approx.
0.302 kg (0.666 lb)
Wire size
Wiring category
(1)
2 – on signal ports
2 – on power ports
Wire type
Use Copper Conductors only
Terminal screw torque 0.6 Nm (4.4 lb-in) max
using a 2.5 mm (0.10 in.) flat-blade screwdriver.
Input circuit type
12/24V sink/source (standard)
24V sink/source (high-speed)
Output circuit type
Relay
24V DC sink transistor (standard
and high-speed)
Power consumption
5 W
Power supply
voltage range
20.4…26.4V DC Class 2, or
Limited Voltage Limited Current Source (LVLC)
I/O rating
Input 24V DC, 8.8 mA
Output 2 A, 240 V AC, General Use
Input 24V DC, 8.8 mA
Output 2 A, 240 V DC, 1 A per point
(Surrounding air temperature 30 °C)
24 V DC, 0.3 A per point
(Surrounding air temperature 65 °C)
Isolation voltage
250V (continuous), Reinforced
Insulation Type, Outputs to Aux
and Network, Inputs to Outputs
Type tested for 60 s @ 720 V DC,
Inputs to Aux and Network,
3250 V DC Outputs to Aux and
Network, Inputs to Outputs
50V (continuous), Reinforced
Insulation Type, I/O to Aux and
Network, Inputs to Outputs
Type tested for 60 s @ 720 V DC,
I/O to Aux and Network, Inputs to
Outputs
Pilot duty rating
C300, R150
N.A.
Min
Max
Solid
0.14 mm
2
(26 AWG)
2.5 mm
2
(14 AWG)
rated @ 90 °C
(194 °F ) insulation max
Stranded
0.14 mm
2
(26 AWG)
1.5 mm
2
(16 AWG)
