Sensor Configuration
Once installed and aligned the sensor must be configured (programmed) to operate
properly. Using the pushbutton under the sensor’s cover or a Configuration Tool such
as RS Networx the user must set the sensor’s address, baud rate and select Light or
Dark operating mode. Note that COS models can only be configured over the network.
The following instructions refer to “local programming.” For programming with a
Configuration Tool, refer to the instructions provided with the tool.
Programming is a two step process.
1. First a Category is selected using the pushbutton.
The RED STATUS Indicator:
a. Confirms Category selection by flashing the same number of times the
pushbutton was pressed to select a category. (1/4 second flashes)
or
b. Flashes once for one full second to indicate an invalid input.
2. Then a setting is input using the pushbutton.
The GREEN STATUS Indicator:
a. Confirms the setting by flashing the same number of times the pushbutton was
pressed to input the setting.
or
b. The RED STATUS Indicator flashes once for one full second to indicate an invalid
input.
Enter Programming Mode
Press the pushbutton for 3 seconds and release it. The RED and GREEN Network
STATUS Indicators each flash twice, alternately, to confirm entry to PROGRAMMING
MODE.
Return to Run Mode
The sensor may be returned to RUN MODE in either of two ways. The user can return
the sensor to RUN MODE from PROGRAMMING MODE at any time by pressing the
pushbutton for 3 seconds and releasing it. The RED and GREEN Network STATUS
Indicators each flash twice, alternately, to confirm return to RUN MODE mode. Or the
sensor will automatically return to RUN MODE from PROGRAMMING MODE
whenever the pushbutton remains unpressed for 15 seconds!
Setting Sensor Address: Valid addresses: 00 thru 63
(factory default: 63)
Category 1. MSD
Press the pushbutton one time, quickly.
The RED STATUS Indicator confirms the selection.
Press the pushbutton once quickly to set the MSD to “1,” twice to set it to “2,” etc. Press
the pushbutton ten times to set the MSD to “0.” The GREEN STATUS Indicator flashes
to confirm the setting; once for a setting of “1,” twice for a setting of “2,” etc.
Category 2. LSD
Press the pushbutton two times, quickly.
The RED STATUS Indicator confirms the selection.
Press the pushbutton once quickly to set the LSD to “1,” twice to set it to “2,” etc. Press
the pushbutton ten times to set the LSD to “0.” The GREEN STATUS Indicator flashes
to confirm the setting; once for a setting of “1,” twice for a setting of “2,” etc.
Category 3. Operating Mode
(default: Light Operate)
Press the pushbutton 3 times, quickly.
The RED STATUS Indicator confirms the selection.
Light Operate: Press the pushbutton once, quickly.
The GREEN STATUS Indicator flashes to confirm the setting.
Dark Operate: Press the pushbutton twice, quickly. The GREEN STATUS Indicator
flashes to confirm the setting.
Category 4. Baud Rate
(default: 125 kb)
Press the pushbutton 4 times, quickly.
The RED STATUS Indicator confirms the selection.
125kb: Press the pushbutton once, quickly.
The GREEN STATUS Indicator flashes to confirm the setting.
250kb: Press the pushbutton twice, quickly.
The GREEN STATUS Indicator flashes to confirm the setting.
500kb: Press the pushbutton 3 times, quickly.
The GREEN STATUS Indicator flashes to confirm the setting.
Category 5. Reset to Factory Default
Press the pushbutton 5 times, quickly.
The RED STATUS Indicator confirms the selection.
Press the pushbutton once.
The GREEN STATUS Indicator flashes to confirm that all settings have been reset to
factory values.
