Properly route fiber optic cables – Rockwell Automation 2090-SCVPx Fiber Optic Cable Installation Quick Reference User Manual
Page 7
Fiber Optic Cable Installation 7
Publication 2090-QR001D-EN-P – April 2005
Properly Route Fiber Optic Cables
Take care when routing through cabinets and right angle raceways.
• Install cables in raceways without loops. Avoid placing fiber optic
cables in raceways and conduits with copper cables to avoid excessive
loading or twisting.
Figure 4 Using Raceways and Conduits
Figure 5 Using Raceways and Conduits
Power Cables
Fiber Optic Cables
