Fiber optic cable mechanical limits – Rockwell Automation 2090-SCVPx Fiber Optic Cable Installation Quick Reference User Manual
Page 4
4 Fiber Optic Cable Installation
Publication 2090-QR001D-EN-P – April 2005
Fiber Optic Cable Mechanical Limits
Catalog Number
Length
meters (in.)
Long Term Bend
Radius No Load
millimeter (in.)
Maximum Tensile Load
Newton (lbs.)
2090-SCVGx-0
Glass
50 to 200
(1968 to 7872)
30.0 (1.2)
< 98 (22)
2090-SCVPx-x
Plastic
0.1 to 32
(4 to 1260)
40.0 (1.6)
< 245 (55)
2090-SCEPx-x
Plastic
0.1 to 32
(4 to 1260)
25.4 (1.0)
< 70 (15)
2090-SCNPx-x
Plastic
0.1 to 32
(4 to 1260)
25.4 (1.0)
< 70 (15)
