Display frequency, Video input level, Language selection – Rockwell Automation 6159 Industrial 17 inch CRT Monitors, Series B User Manual
Page 25
Industrial 17" CRT Monitor
25
Publication 6159-5.1
5.
To adjust the value, press
to advance to the appropriate color.
Press the
<
and
>
arrow keys to adjust the value of the selected
color (0-255).
6.
Press the
key to memorize the settings and complete the
adjustments.
Display Frequency
This option displays the input synchronization signal frequency. Display
the Display Frequency adjustment box to view signal.
Video Input Level
This option allows the user to match the video input signal level to the
computer being used. The user can choose from one of two selections
(0.7V or 1V).
1.
Display the Video Input Level adjustment box.
2.
Press
to toggle to the correct selection.
3.
Press the
key to memorize the settings and complete the
adjustments.
Language Selection
The user can alter the language of the on-screen menu. Selections
include German, French, English, Italian, and Spanish.
1.
Display the Language Selection adjustment box.
2.
Press the
<
or
>
arrow keys to move
;
to the correct selection.
3.
Press the
key to memorize the settings and complete the
adjustments.
