24 Industrial 17" CRT Monitor
Publication 6159-5.1
Rotation
Adjusts for tilt of the image on the screen.
1. Display the Rotation adjustment box.
2. Use the arrow keys to select a value
•
Press < to tilt the image to the left.
•
Press > to tilt the image to the right.
3. Press the key to memorize the settings and complete the
adjustments.
Color Temperature
Adjusts the color white in an image (in Kelvin). The higher the
temperature, the redder, or warmer, the image color scheme. The lower
the temperature, the bluer, or colder, the image color scheme.
Note: Before making any adjustments, record the initial color
setting because memory recall will not reset this value.
1. Display the Color Temperature adjustment box.
2. Press the < and > arrow keys to make one or the following
selections:
•
1 : 9300K
•
2 : 6550K
•
3: User-defined temperature value
3. If you selected “3”, the icon displays in the lower-right corner of
the Color Adjustment control box. This instructs the user to press
to display the User Color Adjustment control box..
4. To enter a user-defined value, you must manually set the red, green,
and blue values.
