32 Industrial 19" CRT Monitor
Publication 6157-UM001A-EN-P
Horizontal Size
Use the horizontal size controls to makes the image wider or narrower.
Note: Before adjusting the horizontal size, you must first center
the image in the screen using the horizontal position
controls.
Pressing
>
toggles between the horizontal size and
horizontal position control boxes.
1. Display the OSD.
2. Use the arrow keys (
>
or
<
) to select the horizontal size box.
3. Press + or – narrow or widen the image on your screen.
4. Proceed to make other adjustments as necessary.
Note: If you wait ten seconds, the display will automatically close
the window, memorize the settings and complete the
adjustments.
Vertical Position
Use the vertical position controls to center the image vertically on the
screen.
Note:
Pressing
>
toggles between the vertical size and vertical
position control boxes.
1. Display the OSD.
2. Use the arrow keys (
>
or
<
) to select the vertical position box.
3. Press + or – to move the image up or down until it is centered on the
screen.
4. Proceed to make other adjustments as necessary.
Note: If you wait ten seconds, the display will automatically close
the window, memorize the settings and complete the
adjustments.
