Appendix a – Rockwell Automation 61C365 4 Output 4-20mA Analog Rail User Manual
Page 38
AĆ2
Appendix A
(Continued)
Output Channels
D Operating range: 4Ć20mA (shortĆcircuit protected)
D Number of channels: 4 (singleĆended)
D Number of commons: 1 (sharedamong all 4 channels)
D Output range of external power supply channels: 5Ć32 VDC
D Resolution: 12 bits binary
D NonĆlinearity: +/1 LSB maximum
D Accuracy: +0.33% of full scale at 25_C maximum
D Thermal drift: 50 ppm/degrees C
D Gain error: + 4 LSB maximum
D Type of converter: 2Ć2 dual DACs on a monolithic IC
D Speedof conversion: Scan Dependent
D Output settling time: 200 usec. maximum
D Loadresistance range: 0Ć1450 Ohms
D Isolation of analog section from host andinput power: 2500V RMS
