8 900 Watt Passive Shunt Module
Product Specifications
Specifications for the passive shunt module are provided in the
following tables. Physical measurements are shown in Figure 4 on
page 9.
General Specifications
Description
Weight
net
3.31 kg (7 lbs)
shipping
4.08 kg (9 lbs)
Resistance
18
Ω
± 10%
Power rating
peak
10 kW
continuous 900
W
Fuse
10 Amp, 700 VDC, fast acting
(Bussmann FWP10A14F)
Environmental Conditions
Value
Vibration
2g at 10 to 2000 Hz
Shock
15g 11 msec half sine
Altitude
1500 m (5000 ft)
Humidity
5% to 95% non-condensing
Ambient operating temperature
1
0° to 50° C (32° to 122° F)
Air flow clearances
155 mm (6.1 in.) on all sides for air flow.
1
Power performance increases about 5.5 W for every 1°C (3.1 W/°F) drop in ambient temperature.
Mounting Hardware
Size
Hex cap screws
1/4 in. - 20
Hex cap screws (metric)
M6
Wiring Size
75°C copper wire
8.4mm
2
(8 AWG)
Terminal Block Screws
Torque
Chrome plated brass
4.0 Nm (35 in.-lbs)
