Rockwell Automation 6153 Industrial Computers (6153, 6154) User Manual
Page 9

Bulletin 6153 and 6154 Industrial Computers with Integrated CRT
9
Publication 6153-2.0
5. Remove the external bezel.
6. Insert the computer in the panel cutout from the front of the
panel.
7. Place the washers (one of each) on the bolts provided and install
through the front panel.
8. Secure with the included lock nuts, tightening them evenly to 25
inch pounds torque.
!
ATTENTION: Mounting nuts must be tightened to a
torque of 25 inch-pounds to provide panel seal and
avoid potential damage to the Bulletin 6153 Industrial
Computer. Allen–Bradley assumes no responsibility for
water or chemical damage to the Bulletin 6153
Industrial Computer or other equipment within the
enclosure due to improper installation.
Important: To assure a proper seal, be sure to install all 14 (4
slots) or 16 (8/12 slots) bolts.
9. Remove the protective adhesive sheet from the screen of the
Industrial Computer. The sheet is designed to prevent scratching
of the polycarbonate screen protector or the optional touchscreen
during shipping and installation. It should be removed before use.
10. Attach the external bezel to the front of the Industrial Computer.
