Bulletin 6153 and 6154 Industrial Computers with Integrated CRT 25
Publication 6153-2.0
Processor/Memory
Processor/Speed (MHz)
486DX4/100 MHz, Pentium/100 MHz,
Pentium/166 MHz
Memory Options 4M (for 486DX4/100 only), 8M, 16M, 32M, 64M
System
System Bus Architecture
16-bit ISA, 8 slots (active motherboard)
16-bit ISA, 4 or 12 slots (passive backplane)
Available Expansion Slots:
Active Motherboard
Passive Backplane 4 full-length ISA, 3 PCI, 1 shared
2 full-length ISA (4 slot) or 10 full length ISA (12 slot)
Serial Ports, Standard 2
Parallel Ports, Standard 1
Operating Systems MS DOS, MS Windows 95, MS Windows NT
Network Support 16-bit Ethernet LAN card
Mass Storage
Internal Drive Bays 2 (4-slot) or 3 (8 or 12 slot)
Diskette Drive 3.5 in., 1.44MB
Hard Disk drives 1.0+GB, 1.5+GB, 2.0+GB EIDE
Operator Input
Keyboard Interface
4-Slot Units Front Lemo style sealed
Rear 5-pin DIN (Standard AT)
8-Slot Units Front 5-pin DIN (Standard AT)
Rear PS2 style
12-Slot Font/Rear 5-pin DIN (Standard AT)
Display
Video Controller VGA, 1MB, 2MB, 4MB
CRT Size 20” diagonal
Nominal Display Area 14.0 in. Horizontal x 10.5 in. Vertical
(356 mm x 267 mm)
Resolution 640 x 480 to 1280 x 1024
Dot Pitch 0.28 mm
Horizontal Scan Rate 30 kHz to 82 kHz
Vertical Scan Rate 40 Hz to 80 Hz
Video Bandwidth 150 MHz
Video Inputs RGB Analog, RS-343A (0.7V peak into 75 Ohms =
100% modulation)
Sync Type Separate Horizontal and Vertical Sync Control. TTL
signal levels.
Sync Polarity Horizontal – Negative or positive
Vertical – Negative or positive
Specifications
