Page 3: Installation instructions, English about this publication

Publication 2711P-IN006B-MU-P - March 2007
Installation Instructions
Mounting Clips
Catalog Number 2711P-RTMC
English
About This Publication
This document provides instructions on how to install the following devices in a
panel or enclosure using the 2711P-RTMC mounting clips. Eight mounting clips are
provided with kit.
• 2711P PanelView Plus terminal
• 2711P PanelView Plus CE terminal
• RAC6182 industrial computer
The mounting clips hold the device tightly against the mounting enclosure. The
number clips used for installation varies by device.
Number
of Clips
Device
Clip Location on Device
4
RAC6182 (all sizes)
PanelView Plus and PanelView Plus CE 700 (all versions)
PanelView Plus and PanelView Plus CE 1000 Touch Only
Top: left and right slots
Bottom: left and right slots
6
PanelView Plus and PanelView Plus CE 1000 Keypad or
Keypad & Touch
PanelView Plus and PanelView Plus CE 1250 (all versions)
Top: left and right slots
Bottom: left and right slots
Sides: left and right slots
8
PanelView Plus and PanelView Plus CE 1500 (all versions)
Top: left and right slots
Bottom: left and right slots
Sides: top and bottom
