10 Micro800 8-Point and 16-Point AC/DC Relay Output Modules
Publication 2085-IN004A-EN-P - September 2012
Insulation strip length 10 mm (0.39 in.)
Wiring category (1) 2 – on signal ports
Wire type Copper
Terminal screw torque. max 0.5…0.6 Nm
(4.4…5.3 lb-in.)
(2)
Bus current draw, max 5V DC, 120 mA
24V DC, 50 mA 5V DC, 160 mA
24V DC, 100 mA
Load current, max (refer to Relay contact, (0.35 power factor) below)
Power dissipation,
total 2.72 W 5.14 W
Relay contact, (0.35 power
factor)
Minimum load, per point 10 mA per point
Off-state leakage, max 1.5 mA
Status indicators 8 yellow indicators 16 yellow indicators
Isolation voltage 240V (continuous), Reinforced Insulation Type, channel to system
Type tested at 3250V DC for 60s
Pilot duty rating C300, R150
Enclosure type rating None (open-style)
North American temp code T4
(1) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines,
publication
1770-4.1 .
(2) RTB hold down screws should be tightened by hand. They should not be tightened using a power tool.
Environmental Specifications
Attribute Value
Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20…65 °C (-4…149 °F)
Temperature, surrounding air, max 65 °C (149 °F)
Temperature, non-operating IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock):
-40…85 °C (-40…185 °F)
General Specifications
Attribute 2085-OW8 2085-OW16
Maximum Volts Amperes Amperes
Continuous Volt-Amperes
Make Break Make Break
120V AC 15 A 1.5 A 2.0 A 1800 VA 180 VA
240V AC 7.5 A 0.75 A
24V DC 1.0 A 1.0 A 28 VA
125V DC 0.22 A
