6 Kinetix 6000M Series B Network Cable

Rockwell Automation Publication 2090-IN052A-EN-P - May 2014

Schematic and Connector Pinouts

The diagrams provides wire colors and pinouts for the Kinetix 6000M network cables.

Network Communication Cable Schematic

Network Communication Cable Pinouts

Network Communication Cable Configurations

1
4
2
3
5

1
4
2
3
5

Blue

White/Blue

White/Brown

Brown

Shield

Twisted Pair

Shield

Wire Connection

(1)

Shield connects to the threaded metal end of both connectors.

(1) (1)

Green

Male Connector
Pinouts

Female Connector
Pinouts

2090-CNSSPRS-AA

xx

Straight Male and Right-angle Female

2090-CNSRPSS-AA

xx

Right-angle Male and Straight Female

(1)

2090-CNSSPSS-AA

xx

Straight Male and Straight Female

2090-CNRSPRS-AA

xx

Right-angle Male and Right-angle Female

(1)

(1)

Not for connection to an IPIM module.
