3 - configuring the dl5 slave, Chapter objectives, Configuring a dl5 slave – Rockwell Automation 2706-D11JS_D21JS Dataliner DL5 Slave Displays User Manual
Page 21: Configuration cables, Configuring the dl5 slave, Chapter
Publication 2706-6.4
Chapter
3
Configuring the DL5 Slave
Chapter Objectives
This chapter describes how to configure the DL5 display using an ASCII
programming terminal or personal computer running a terminal emulation
program such as HyperTerminal (Windows 95 or 98).
Configuring a DL5 Slave
You can configure a DL5 Slave with:
•
an ASCII (dumb) terminal connected to the DL5 Slave RS-232 port
•
a personal computer connected to the DL5 Slave RS-232 port and
running a terminal emulation program.
Configuration Cables
The following cables are available for configuring the DL5 Slave.
Cable:
Use With:
2706-NC12
Personal computers with 25-pin female com port
connector. DEC VT52, VT100, or VT101 terminals.
Allen-Bradley RAC 6000 industrial computers.
2706-NC13
Personal computers with 9-pin female com port
connector (IBM AT and compatible). Allen-Bradley RAC
6000 industrial computers.
2706-NC14
Allen-Bradley RAC 6000 industrial computers (PC/XT).
2706-NC15
Allen-Bradley Industrial Terminals T1 through T4 (25-pin
male connector)
2707-NC2
DL40 master or PanelView RS-232 printer port (requires
male-female pin adapter).
