Backlight Replacement 3
Publication 2711P-IN019D-EN-P - February 2007
Precautions
Disconnect power from the terminal before installing or replacing any components.
Take care not to touch any of the exposed electronic components during
installation.
Required Tools
These are the tools required to replace backlights for PanelView Plus and
PanelView Plus CE terminals:
• #00, #1, and #2 Phillips screwdriver
• Electrostatic discharge (ESD) wristband
Remove Display Module Bezel
Follow these steps to remove the bezel.
1. Disconnect power from the terminal.
2. Set the terminal, display side down, on a flat stable surface.
3. Remove the two screws that secure the small metal plate to the back of the
display module only on touch screen terminals.
ATTENTION
Disconnect all power from the terminal before installing or replacing any
components. Failure to disconnect power may result in electrical shock or
damage to the terminal.
ATTENTION
Work in a static free environment and wear a properly grounded electrostatic
discharge (ESD) wristband.
Be careful when touching any of the exposed electronic components to prevent
damage from ESD.
ATTENTION
Wear a properly grounded ESD wristband before touching any of the electronic
components in the display module.
Be careful when touching any of the exposed electronic components to prevent
damage from ESD.
