Power with Brake Connector Kit for TL-Series Servo Motors Installation Instructions 5
Publication 2090-IN018A-EN-P - June 2010
Assemble the Power with Brake Connector Kit
Follow these steps to assemble your TL-Series (Bulletin TLY) connector kit.
1. Slide the backshell onto the cable.
2. Remove the insulation from the end of the wires to expose a maximum of
2.5 mm (0.1 in.) of wire.
3. Crimp a socket on each wire.
4. Refer to the Parts List on page 4 for the correct socket type. Refer to the
Power Connector table on page 6 for the correct wire and connector
position for each wire.
5. Insert the socket of each wire into the appropriate position at the back of the
connector housing.
6. Ground the cable shield.
7. Screw the backshell onto the connector housing.
8. Select the type of backshell clamp, and determine its appropriate
orientation.
The type and orientation of the backshell clamp is dependent on your application.
9. Tighten the backshell clamp screws until the backshell clamp applies
sufficient pressure on the cable jacket to retain the cable.
ATTENTION: To prevent electrical shock, disconnect the connector, motor, and
drive from the power source before installing or servicing.
This device should be used only in an enclosure that prevents exposure to
contaminants.
IMPORTANT Do not over-tighten the backshell clamp screws.
Applying excessive force may damage the threads in the plastic backshell.
