4 Power with Brake Connector Kit for TL-Series Servo Motors Installation Instructions
Publication 2090-IN018A-EN-P - June 2010
Parts List
These items are supplied in the connector kit.
Tool List
Use these tools to assemble the connector kit.
Required Tools
Item Qty.
Wire
Size
Insulation
Diameter
Insulation
Strip Length
Tyco AMP Part No.
mm² (AWG)
mm (in.)
mm (in.)
Power sockets
8
0.8…1.4
(18…16)
2.54 (0.10) max
2.5 (0.1)
66101-4
Brake sockets
15
66505-9
Housing 1
N/A
205839-3
Backshell
(1)
(1)
The maximum cable diameter, including wiring and jacket material, allowed by this backshell is 11.51 mm (0.45 in.),
1
N/A 206070-8
IMPORTANT
Tools are not provided in the connector kit.
Item
Tyco AMP Part No.
Hand crimp tool - power contacts
58495-1
Extraction tool - power contact
305183
Extraction tool - ground contact
725840-1
Insertion tool - power, brake, and ground contacts
91002-1
Wire cutter
N/A
Wire stripper
Screwdriver, size 0 or 1 Phillips
Needle-nose pliers (optional)
