AC (12-120V) Output Module
15
Publication 1771ĆIN024B-EN-P - November 2002
Enclosure Type Rating
None (open-style)
Keying
Between 10 and12
Between 20 and22
Fuse
12A, 250V rectifier fuse (1/4 x 1Ć1/4 inch), Bussman GBB12, IEC 127
Type F (black)
FieldWiring Arm
Standard
Optional
Catalog Number 1771ĆWH
Catalog Number 1771ĆWHF (fused)
Wiring Arm Screw Torque
9 pound-inches (1.02Nm)
Relay Compatibility
700-CL110A1
700-HB32A1
700-HC14A1
700-HC14A1-4
700-HF32A1
700-HT12AA1
100-A09
100-A18
100-A30
Certifications
(when product is marked)
UL
UL ListedIndustrial Control Equipment
CSA
CSA CertifiedProcess Control Equipment
CSA
CSA CertifiedProcess Control Equipment for Class I,
Division 2 Group A, B, C, D Hazardous Locations
CE
2
European Union 89/336/EEC EMC Directive,
compliant with:
EN 50082-2, Industrial Immunity
EN 61236, Meas./Control/Lab., Industrial Requirements
EN 61000-6-2, Industrial Immunity
EN 61000-6-4, Industrial Emissions
CE
2
European Union 73/23/EEC LVD Directive,
compliant with:
EN 61131-2, Programmable Controllers
C-Tick
2
Australian Radiocommunications Act, compliant with:
AS/NZS 2064, Industrial Emissions
1
You use this conductor category information for planning conductor routing as described in publication 1770Ć4.1, Industrial
Automation Wiring and Grounding Guidelines.
2
See the Product Certification link at www.ab.com for Declarations of Conformity, Certificates and other certification details
