ProcessLogix Controller 11
Publication 1757-IN901D-EN-P - May 2007
Verify Network Connection
To verify that the controller is communicating over the network, complete the following
steps.
1. In RSLinx, select Communications > RSWho.
The RSWho window opens.
2. Expand the ControlNet or Ethernet node and verify that the 1757-PLX52 controller
is listed in the backplane.
IMPORTANT
The 1757-PLX52 controller is supplied with only the boot code installed. You
must update the controller firmware before you can use it in your system.
Refer to the Installation and Upgrade Guide that was shipped with your
ProcessLogix software for more information.
