44 ControlLogix Controller and Memory Board
Publication
1756-IN101L-EN-P - June 2008
ControlLogix Memory Board Specifications - 1756-M1, 1756-M2, 1756-M3,
1756-M12, 1756-M13, 1756-M14, 1756-M16, 1756-M22, 1756-M23, and
1756-M24
Attribute
Value
Temperature, operating
EC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
• 0 … 60 °C (32…140 °F)
Temperature, storage
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal
Shock):
-40… 85 °C (-40…185 °F)
Relative humidity
EC 60068-2-30 (Test Db, Unpackaged Damp Heat):
• 5…95% noncondensing
Vibration
IEC 60068-2-6 (Test Fc, Operating):
• 2 g @ 10…500 Hz
Shock, operating
IEC60068-2-27 (Test Ea, Unpackaged Shock):
• 30 g
Shock, nonoperating
IEC60068-2-27 (Test Ea, Unpackaged Shock):
• 50 g
Emissions
CISPR 11:
• Group 1, Class A
ESD immunity
IEC 61000-4.2:
• 6 kV indirect contact discharge
• 8 kV air discharge
Radiated RF immunity
IEC 61000-4-3:
• 10V/m with 1 kHz sine-wave 80% AM from 80…2000 MHz
• 10V/m with 200 Hz 50% Pulse 100% AM at 900 MHz
• 10V/m with 200 Hz 50% Pulse 100% AM at 1890 MHz
• 1V/m with 1 kHz line-wave 80% AM from 2.0…2.7 GHz
Enclosure type rating
None, open style
North American temperature
code
T4A
IEC temperature code
T4
Intrinsically safe
No
