12 FLEX I/O Isolated Output HART Analog Module
Publication 1794-IN120C-EN-P - April 2009
4 Current O4 A-8
Current O4 Ret A-9
5 Current O5 A-10
Current O5 Ret A-11
6 Current O6 A-12
Current O6 Ret A-13
7 Current O7 A-14
Current O7 Ret A-15
-V DC common For catalog numbers 1794-TB3 and 1794-TB3S, terminals B-16…33 are
internally connected in the terminal base unit.
+V DC power For catalog numbers 1794-TB3 and 1794-TB3S, terminals C-34…51 are
internally connected in the terminal base unit.
Input Map
Word Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 F7 F6 F5 F4 F3 F2 F1 F0 Diagnostic Status
1 Reserved
2 C
7 C
6 C
5 C
4 C
3 C
2 C
1 C
0 Reserved
3 X
7 X
6 X
5 X
4 X
3 X
2 X
1 X
0 Reserved
Fn:
Cn:
Xn:
Channel n Wire Fault Alarm for open or short circuit
(1)
Channel n HART Current Fault
HART Device Transmitter present
0: False 1: True
0: False 1: True
0: False 1: True
Note: Reserved data may not be shown in certain controller software
Wire Connections
Channel Signal
Type Label
Markings
Catalog Numbers
1794-TB3 or 1794-TB3S Terminal
