AC (120/240V) Output Module
4
Publication 1771ĆIN031B-EN-P - November 2002
The 1771-OAN ac output module is a source output and requires a
sink input. A sink input provides a path to ground and a source
output provides a positive voltage path.
This module is not compatible with 2-slot addressing. You must use
1-slot addressing with restrictions, or 1/2-slot addressing with no
restrictions.
IMPORTANT
You must use this module in a 1771-A1B thru
-A4B or later 1771 I/O chassis. Refer to the
Table below for processor compatibility.
Processor Compatibility Chart
System Type
Use with Processors:
Local
MiniĆPLCĆ2/02 (cat. no. 1772ĆLZ, ĆLZP)
MiniĆPLCĆ2/16 (cat. no. 1772ĆLX, ĆLXP)
MiniĆPLCĆ2/17 (cat. no. 1772ĆLW, ĆLWP)
PLCĆ5/15, Series B and later (cat. no. 1785ĆLT)
Remote (with a 1771ĆASB remote
I/O adapter)
PLCĆ2/20 (cat. no. 1772ĆLP2)
PLCĆ2/30 (cat. no. 1772ĆLP3)
PLCĆ3 (cat. no. 1775ĆL1, ĆL2, ĆL3, ĆL4)
PLCĆ3/10 (cat. no. 1775ĆLP4, ĆLP8)
PLCĆ5/15, Series B and later (cat. no. 1785ĆLT)
Do not place this module in the same I/O chassis as the 1771-IX
thermocouple module. You can use this module in the same chassis
as the 1771-IXE thermocouple module.
The controller or I/O chassis power supply, connected through the
backplane of the I/O chassis, powers the logic circuitry of the output
modules. The maximum current drawn from this supply is 800mA.
PreĆinstallation
Considerations
Power Supply
Requirements
