background image

ArmorPoint 24V DC 16 Point Input and Output Modules, Series A 15

Publication

1738-IN023B-EN-E - February 2010

ArmorPoint 24V DC Output Modules, Series A - 1738-OB16E19M23,
1738-OB16EM12, 1738-OB16E25DS

Attribute

Value

Number of outputs

1 group of 16, nonisolated sourcing outputs

On-state voltage drop

0.2V DC maximum

On-state voltage

10V DC minimum

24.V DC nominal

28.8V DC maximum

On-state current

per channel

1.0 mA minimum

0.5 A maximum, electronically protected

Off-state voltage

28.8V DC maximum

External DC supply voltage

10...28.8V DC range

24V DC nominal

Off-state current leakage

0.5 mA

Output current rating

4.0 A per module maximum

0.5 A per channel maximum

Output surge current

1 A maximum, electronically protected

Output delay time

(1)

OFF to ON /

ON to OFF


0.1 ms

Output point density

16

Pilot duty rating

1.3 A Inrush

(1)

OFF to ON or ON to OFF delay is time from a valid output on or off signal to output energization or
de-energization.
