4 ArmorPoint 4-Channel 24V dc Analog Output Modules, Series A
Publication 1738-IN025C-EN-P - March 2010
About the Module
The ArmorPoint I/O family (Cat. no. 1738) consists of modular I/O
modules. The sealed IP67 housing of these modules requires no enclosure.
(Note that environmental requirements other than IP67 may require an
additional appropriate housing.) I/O connectors are sealed M12 style. The
mounting base ships with the module. The 1738-OE4CM12 module is shown
below.
ATTENTION
Make sure all connectors and caps are securely tightened to properly seal the
connections against leaks and maintain IP enclosure type requirements.
ATTENTION
To comply with the CE Low Voltage Directive (LVD), all connected I/O must be
powered from a source compliant with the following:
Safety Extra Low Voltage (SELV) or Protected Extra Low Voltage (PELV).
MOD
NET
0
1
1738-OE4CM12/A
Analog Current Out
0 1
2
3
2 3
Connector M12-A
LED Indicators
44369
1738-OE4CM12
Connector M12-B
Connector M12-C
Connector M12-D
